Modules with special functions PR ELECTRONICS 2224, 2281, 2289, 3532, 5343B, etc.

2224 Proportional valve control
Application: Standard versions
Functions: Modules with special functionality
Installation: 11-pin socket
Input: 0...20 mA / (-)10...+10 VDC
Output: 2700 mA @ 12 VDC / 1500 mA @ 24 VDC
Supply Voltage: 12 VDC / 24 VDC
Number of channels: 1 channel
Programming: By buttons on the front panel
Features: Dead Zone / Rise time (linear change of the signal)

2261 Load cell amplifier, mV amplifier
Application: Standard versions
Functions: Modules with special functionality
Installation: 11-pin socket
Input: (-)40...+100 mV
Output: 0...20 mA / 2...10 VDC
Supply voltage: 19.2 ... 28.8 VDC
Number of channels: 1 channel
Programming: By buttons on the front panel
Features: Converter Power Supply / Load Cell Amplifier

2281 Up-down linear measurement controller, position transmitter via 2-phase converter
Application: Standard versions
Functions: Modules with special functionality
Installation: 11-pin socket
Input: NPN(3x) / PNP(3x)
Output: 0...20 mA / 2...10 VDC
Supply voltage: 19.2 ... 28.8 VDC
Number of channels: 1 channel
Programming: By buttons on the front panel
Features: Rise time (Linear signal change) / Time measurement

2286 PID controller, signal comparison, leak tracking, external switching setpoint
Application: Standard versions
Functions: Modules with special functionality
Installation: 11-pin socket
Input: NPN(3x) / PNP(3x)
Output: 0...20 mA / 2...10 VDC
Supply voltage: 19.2 ... 28.8 VDC
Number of channels: 1 channel
Programming: By buttons on the front panel
Features: Rise time (Linear signal change) / Time measurement

2289 Analog PID controller, analog multiplexer, mathematical operations, peak value measurement
Application: Standard versions
Functions: Modules with special functionality
Installation: 11-pin socket
Input: 0...20 mA / 0...10 VDC / Pt100 / Potentiometer > 170 ohm / NPN /PNP
Output: 0...20 mA / 2...10 VDC
Supply voltage: 19.2 ... 28.8 VDC
Number of channels: 2 inputs
Programming: By buttons on the front panel
Features: Analog Multiplexer / Mathematical Functions / Peak Value Measurement / Analog PID Controller

3532 Valve position/direction transmitter
Application: Standard versions
Functions: Modules with special functionality
Installation: Cabinet
Input: 2-phase converter
Output: 0...20 mA
Supply voltage: 19.2 ... 28.8 VDC
Number of channels: 2 channels
Programming: -
Features: -

5343A Level transmitter for ohmic level sensors up to 100K
Application: Standard versions
Functions: Modules with special functionality
Installation: In the sensor housing
Input: Line resistance 0...100 kOhm
Output: 4...20 mA
Supply voltage: Serial connection
Number of channels: 2 channels
Programming: PC
Features: Sensor failure detection/ Signal Linearization by user

5343B Level Transmitter for Ohmic level sensors (Ex)
Application: Versions for explosive zones (Ex)
Functions: Modules with special functionality
Installation: In the sensor housing
Input: Line resistance 0...100 kOhm
Output: 4...20 mA
Supply voltage: Serial connection
Number of channels: 2 channels
Programming: PC
Features: Sensor failure detection/ Signal Linearization by user
